Kaichi Nr.: SZ-025-16
Brand:KaiChi
Radiator Type:Brazed Aluminum Core
Size In Inch:17-11/16 In X 27-1/16 In X 5/8 In
Size In MM:450mm X 688mm X PA16
Min Order Qty:10pcs
Payment Term: T/T
Incoterm: FOB,CIF
Shipping Ports: Shenzhen or Ningbo in China
Item Specifics:
| Part Type: | Auto Radiator | Brand: | KaiChi |
| Manufacturer Warranty: | 1 Year | Manufacturer Part Number: | SZ-025-16 |
| Height: | 17-11/16 In./450mm | Width: | 27-1/16 In./688mm |
| Thickness: | 5/8 In./16mm | Inlet Diameter: | 1-3/8 In./34mm |
| Outlet Diameter: | 1-3/8 In./34mm | Tank Material: | Plastic |
| Core Material: | Aluminum | Trans Oil Cooler: | Brass/Concentric |
| Trans Oil Cooler Central Distance: | 13-3/4 In./350mm | Rows: | 1 |
Applications：
| Suzuki Grand Vitara Base V6 2.7L 2006-2008 |
| Suzuki Grand Vitara GL V6 2.7L 2006-2008 |
| Suzuki Grand Vitara GLS V6 3.2L 2009-2010 |
| Suzuki Grand Vitara GLS V6 2.7L 2006-2008 |
| Suzuki Grand Vitara JA V6 2.7L 2008 |
| Suzuki Grand Vitara JLX V6 3.2L 2009-2010 |
| Suzuki Grand Vitara JLX V6 2.7L 2008 |
| Suzuki Grand Vitara JX V6 2.7L 2008 |
| Suzuki Grand Vitara Limited V6 3.2L 2010 |
| Suzuki Grand Vitara Limited V6 2.7L 2008 |
| Suzuki Grand Vitara Luxury V6 3.2L 2009 |
| Suzuki Grand Vitara Luxury V6 2.7L 2006-2008 |
| Suzuki Grand Vitara Premium V6 2.7L 2006 |
| Suzuki Grand Vitara SWT V6 2.7L 2007-2008 |
| Suzuki Grand Vitara XSport V6 3.2L 2009-2010 |
| Suzuki Grand Vitara XSport V6 2.7L 2006-2008 |
| Suzuki Grand Vitara MK II JB416X M16A 1.6 VVT 2005-2015 |
| Suzuki Grand Vitara MK II JB627 H27A 2.7 VVTI 2007-2008 |
| Suzuki Grand Vitara MK II JB632W N32A 3.2 VVTI 2008-2015 |
| Suzuki Grand Escudo MK II JB416X2 M16A 1.6 VVT 2005-2008 |
Cross Reference:
Cross Reference information is provided as a guide only. Please refer to the Applications, Part Specifications and Drawings to verify fit.
| DPI | 2920 |
| SPI | CU2920 |
| APDI | 8012920 |
| TYC | 2920 |
| CSF | 3443 |
| VALEO Europe | 735580 |
| DENSO | 221-9410 |
| DENSO Europe | DRM47018 |
| Vista-Pro | 434034 |
| NRF | 550105 |
| AKS DASIS | 320042N |
| AVA QUALITY COOLING | SZ2102 |
| NISSENS Number | 64253 |
| Partslink | SZ3010139 |
OEM Part Number:
| 1770066J10 |
